All Welded in harsh environment Pressure Sensor PC11B

l  Full welded seal, can be used in harsh environment

l  High performance, all solid, corrosion resistant

l  High accuracy and stability

l  Strong anti-interference, good long-term stability

l  Constant current excitation option

l  Customization available



 PC11B all welded pressure sensor, China pressure sensor, wotian pressure sensor,  pressure  sensor

PC11B all welded pressure sensor is to package PC10 pressure sensor into the workpiece with standard pressure connection. Nanjing Wotian Technology Co., Ltd is a Chinese manufacturer that produces the pressure sensors and transmitters.

Product Parameters

Pressure range

Pressure range

-100kPa, 10kPa, 35kPa, 70kPa, 100kPa, 250kPa,   400kPa, 600kPa,   1MPa, 1.6MPa, 2.5MPa, 4MPa, 6MPa, 10MPa, 16MPa, 25MPa, 40MPa, 60MPa, 100MPa

Pressure reference

Gauge pressure | Absolute pressure | Sealed   gauge pressure

Overpressure

200%F.S.(<10MPa) | 150%F.S.(≥25MPa)

Output signal

Zero output

±2mV

Span output

1.5mA Excitation: ≥40mV (≤35kPa); ≥60mV (Other   ranges) |

10V Excitation: ≥60mV (≤35kPa); 80~120mV (Other   ranges)

Specification

Excitation

1.5mA | 10VDC

Compensated temp.

0-60 (≤35kPa) | -10-70 (Other   ranges)

Operating temp.

-40-125

Storage temp.

-40-125

Zero temp. coefficient

0.02%F.S. /(≥100kPa)   | 0.04%F.S. /(<100kPa)

Span temp. coefficient

0.02%F.S. /(≥100kPa)   | 0.04%F.S. /(<100kPa)

Insulation resistance

200Mohm/250VDC

Input impedance

2kΩ-5kΩ

Long term stability

≤0.2%F.S.S/year

Vibration

20g   (20-5000Hz)

Shock

100g (11ms)

Response time

≤1ms(up to 90%F.S.)

Oil   filling

Silicon oil

Material

Housing: Stainless steel 304 | Diaphragm:   Stainless steel 316L

Medium compatibility

All the liquids and gases   compatible with the diaphragm
